LELIT Espresso Machine - Victoria

• LELIT58 commercial group (58 mm), compatible with LELIT58 tools
• Brass single boiler (300 ml)
• PID temperature control for coffee and steam via LCC (high-resolution OLED display)
• Activatable pre-infusion, automatic washing cycle, and customizable standby time
• Display of coffee/steam/hot water temperatures and extraction time
• Reserve mode: finishes current extraction if the water tank runs out
• Backlit coffee pressure gauge
• 3-way solenoid valve: dry coffee puck at the end of extraction
• Multi-directional steam/hot water wand
• Backlit stainless steel buttons
• Brushed stainless steel body, large cup warmer, drip tray with grid
• 2.5 L water tank with low water indicator
• Tall cup friendly
• 15 bar vibratory pump

• Hot coffee beverages: Espresso, Double espresso
• Hot water
• Milk system: Steam wand

Single boiler: espresso is prepared, then switched to steam mode to texture the milk.

First Start-up

1. Install the included water softener filter (35 L) and fill the tank.
2. Turn on the machine using the switch: the Lelit logo will appear, and the indicator lights will briefly illuminate. On the very first start-up, the machine automatically fills the boiler: water will flow from the group head for about 40 seconds, with the Lelit logo flashing.
3. The LCC screen displays the boiler temperature as it rises. The machine is ready when "OK" is displayed.

Preparing an Espresso

1. Insert the chosen filter into the preheated portafilter and dose the coffee (guidelines: 9-11 g for a single-dose filter, 14-18 g for a double-dose filter).
2. Tamp, clean the filter rim, then lock the portafilter onto the group head.
3. Place the cup(s), activate the lever to start extraction; the pressure gauge needle should be in the green zone. Return the lever to stop.

Steam and Hot Water

• Single Boiler: After espresso, switch to steam mode and wait for the boiler to reach temperature.
• Purge the nozzle for approximately 2 seconds to release condensation, froth the milk, then close and return to coffee mode.
• The multi-directional nozzle also dispenses hot water.

Maintenance

• Weekly: clean surfaces with a damp microfibre cloth; carefully clean the steam wand and portafilter after each use.
• Backflushing with the blind filter and powder detergent (enabled by the 3-way solenoid valve).

• Group: Commercial LELIT58 (58 mm) 58 mm portafilter
• Boiler: Single brass boiler, 300 ml
• Control: PID (coffee and steam) via LCC
• Pump pressure: 15 bar
• Water tank: 2.5 L
• Dimensions (W x D x H): 22.5 × 27 × 27 cm
• Weight: 9.2 kg
• Power supply: 230 V / 50 Hz
• Power: 1200 W
